Ibis DV9 NGX Bike 2023
Original price was: $2,975.00.$1,611.00Current price is: $1,611.00.
‘
Ibis DV9 NGX Bike 2023
For Racing or Shredding
Mountain bikes have become more versatile than ever before. Trail bikes are great for aggressive riding but aren’t that great out in a cross-country race, until now. The Ibis DV9 NGX Bike is a lightweight carbon do-anything, go-anywhere hardtail. It features a down-country geometry with a 66.5° head tube angle with a 120mm travel fork. The frame is compatible with 100mm to 140mm travel forks. The frame features internal cable routing, integrated frame protection, chainstay protection, and a threaded bottom bracket.
The NGX version of the Ibis DV9 comes with a SRAM NX/GX 12-speed drivetrain. The gearing includes a cassette that has an ultra-wide 10-52T gear range that makes climbing a breeze. SRAM G2 R hydraulic disc brakes provide excellent stopping power so you can descend under control. Ibis 933 Aluminum Rims are paired with Maxxis Recon Race that can be set up tubeless for a smoother ride, better traction, and fewer flats. With the KS Rage-i Dropper Post, you’ll be able to quickly lift and lower your saddle with the press of a lever.
Features
- Carbon fiber frame with internal cable routing, integrated frame protection, chainstay protection, and a threaded bottom bracket
- SRAM NX/GX 12-speed drivetrain performs well in various conditions
- SRAM G2 R 4-piston hydraulic disc brakes provide excellent stopping power
- Tubeless-ready rims and tires for a smoother ride, better traction, and fewer flats
- KS Rage-i Dropper Post quickly lists and lowers your saddle with the press of a lever
| Frame | Carbon Fiber |
|---|---|
| Fork | Fox Float 34 Performance, Step-Cast, GRIP, 120mm Travel |
| Rear Shock | Carbon |
| Headset | Cane Creek 40: IS 41/28.6 Upper, IS 52/40 Lower |
| Shifters | SRAM NX Eagle 12-Speed |
| Front Derailleur | Nope |
| Rear Derailleur | SRAM GX Eagle, 12-Speed |
| Crankset | SRAM NX Eagle DUB, 30T Alloy Ring, 24mm Spindle |
| Bottom Bracket | SRAM DUB BSA |
| Chain | SRAM NX Eagle |
| Cassette | SRAM XG-1275, 10-52T |
| Brakes | SRAM G2 R 4-Piston, 180/180mm Rotors |
| Wheelset | Ibis 933 Aluminum, Ibis Logo Boost Hubs |
| Tires | Maxxis Recon Race 29×2.4″ Exo/TR WT |
| Handlebar | Ibis Aluminum, 780mm Wide |
| Stem | Ibis 31.8mm, 40/50mm |
| Grips/Bar Tape | Lizard Skin Charger Evo |
| Seatpost | KS Rage-i Dropper, 125/150/170mm Travel |
| Seatclamp | Bolt-Type |
| Saddle | WTB Silverado |
| Intended Use | Trail, XC |
Note: Components are subject to change without notice.
| Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| A: Seat Tube Length | 355 | 406 | 457 | 508 |
| B: Effective Top Tube | 580 | 608 | 640 | 675 |
| C: Stack | 615 | 622 | 635 | 658 |
| D: Reach | 404 | 435 | 470 | 511 |
| E: BB Height | 308 | 308 | 308 | 308 |
| F: BB Drop | 65 | 65 | 65 | 65 |
| G: Head Tube Length | 85 | 95 | 110 | 135 |
| H: Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| I: Seat Tube Angle | 74 ° | 74.5 ° | 75 ° | 76 ° |
| J: Standover Height | 693 | 714 | 762 | 776 |
| K: Chainstay Length | 425 | 425 | 425 | 425 |
| L: Wheelbase | 1110 | 1145 | 1186 | 1237 |
| Crank Arm Length | 170 mm | 170 mm | 175 mm | 175 mm |
| Stem Length | 40 mm | 40 mm | 50 mm | 50 mm |
| Handlebar Width | 780 mm | 780 mm | 780 mm | 780 mm |
| Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| A: Seat Tube Length | 14.0 | 16.0 | 18.0 | 20.0 |
| B: Effective Top Tube | 22.8 | 23.9 | 25.2 | 26.6 |
| C: Stack | 24.2 | 24.5 | 25.0 | 25.9 |
| D: Reach | 15.9 | 17.1 | 18.5 | 20.1 |
| E: BB Height | 12.1 | 12.1 | 12.1 | 12.1 |
| F: BB Drop | 2.6 | 2.6 | 2.6 | 2.6 |
| G: Head Tube Length | 3.3 | 3.7 | 4.3 | 5.3 |
| H: Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| I: Seat Tube Angle | 74.0 ° | 74.5 ° | 75.0 ° | 76.0 ° |
| J: Standover Height | 27.3 | 28.1 | 30.0 | 30.6 |
| K: Chainstay Length | 16.7 | 16.7 | 16.7 | 16.7 |
| L: Wheelbase | 43.7 | 45.1 | 46.7 | 48.7 |
| Crank Arm Length | 170 mm | 170 mm | 175 mm | 175 mm |
| Stem Length | 40 mm | 40 mm | 50 mm | 50 mm |
| Handlebar Width | 780 mm | 780 mm | 780 mm | 780 mm |
