Orbea Wild M-ltd E-bike 2024
Original price was: $11,050.00.$7,982.00Current price is: $7,982.00.
‘
Orbea Wild M-LTD E-Bike 2024
Beyond Power
E-bikes are designed to remove many of the barriers that prevent people from riding. Hills become easier, longer distances feel shorter, and rough conditions feel tamer. With an e-MTB, you’ll be able to conquer more terrain. The Orbea Wild M-LTD 20mph E-Bike tames the wildest trails but always feels alive, energetic, and involved rather than the detached, numb ride of many e-bikes. It is an enduro mountain bike that uses 170mm of travel on the front and 160mm of travel on the rear. The frame is made of OMR carbon fiber and features internal cable routing, a secure battery system, integrated frame protection, and a clean cockpit. With the Bosch Performance Line CX-R Motor, you’ll get up to 20mph of pedal assist so you can conquer any obstacle.
The M-LTD version of the Orbea Wild comes with a SRAM XX Eagle AXS wireless electronic 12-speed drivetrain. This includes a cassette that has an ultra-wide 10-52T gear range that makes climbing and pedaling through difficult terrain much easier. SRAM Code Ultimate Hydraulic Disc Brakes provide excellent stopping power so you can descend with confidence. OQUO Mountain Control MC32LTD Power tubeless-ready wheels are paired with Maxxis tires that can be set up tubeless for a smoother ride, better traction, and fewer flats. With the Fox Transfer Factory Kashima Dropper Post, you’ll be able to quickly lift and lower your saddle with the press of a lever.
Features
- OMR Carbon Frame with internal cable routing, a secure battery system, integrated frame protection, and a clean cockpit
- SRAM XX Eagle AXS 12-speed drivetrain performs extremely well in all riding conditions
- SRAM Code Ultimate Hydraulic Disc Brakes provide excellent stopping power
- Tubeless-ready rims and tires for a smoother ride, better traction, and fewer flats
- Fox Transfer Factory Dropper Post quickly lifts and lowers your saddle with the press of a lever
- Bosch Performance Line CX-R Motor with a Bosch Powertube 625Wh Battery
| Frame | OMR Carbon Fiber, Concentric Boost 12x148mm |
|---|---|
| Fork | Fox 38 Float Factory GRIP2 Kashima, 15x110mm, 170mm Travel |
| Rear Shock | Fox Float X2 Factory Trunnion 2-Pos Kashima, 205x65mm |
| Headset | Alloy 1-1/2″ Black Oxidated Bearing |
| Shifters | SRAM AXS Pod Ultimate, 12-Speed |
| Front Derailleur | What? |
| Rear Derailleur | SRAM XX Eagle AXS |
| Crankset | SRAM XX for Bosch, DM 34T Boost |
| Bottom Bracket | – |
| Chain | SRAM XX Eagle, 12-Speed |
| Cassette | SRAM XX-1297 Eagle, 10-52T |
| Brakes | SRAM Code Ultimate Hydraulic Disc |
| Wheelset | OQUO Mountain Control MC32LTD Power |
| Tires | Maxxis Assegai 29×2.5″ WT FB 120 3C MaxxTerra EXO+ TR / Minion DHR II 29×2.4″ WT FB 120 3C MaxxTerra EXO+ TR |
| Handlebar | OC Mountain Control MC10 Carbon, 20mm Rise, 800mm Wide |
| Stem | OC Mountain Control MC10 Alu SL, 0° |
| Grips/Bar Tape | Orbea |
| Seatpost | Fox Transfer Factory Kashima Dropper, 31.6mm |
| Seatclamp | Bolt-Type |
| Saddle | Fizik Terra Aidon X1 145mm |
| Intended Use | Trail, All-Mountain, Enduro |
| Motor | Bosch Performance Line CX-R BDU3741 |
| Battery | Bosch Powertube 625Wh Horizontal |
| Display | Bosch System Controller BCR3100 |
Note: Components are subject to change without notice.
| Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| A: Seat Tube Length | 415 | 415 | 435 | 460 |
| B: Effective Top Tube | 573 | 595 | 622 | 649 |
| C: Stack | 621 | 630 | 639 | 648 |
| D: Reach | 435 | 455 | 480 | 505 |
| E: BB Height | 353 | 353 | 353 | 353 |
| F: BB Drop | 25 | 25 | 25 | 25 |
| G: Head Tube Length | 110 | 120 | 130 | 140 |
| H: Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| I: Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| J: Standover Height | 700 | 700 | 700 | 700 |
| K: Chainstay Length | 448 | 448 | 448 | 448 |
| L: Wheelbase | 1223 | 1247 | 1277 | 1306 |
| Crank Arm Length | 160 mm | 160 mm | 160 mm | 160 mm |
| Stem Length | 40 mm | 40 mm | 50 mm | 50 mm |
| Handlebar Width | 800 mm | 800 mm | 800 mm | 800 mm |
| Frame Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| Rider Height | 59.1″ – 68.9″ 150 – 175 cm |
63″ – 72.8″ 160 – 185 cm |
66.9″ – 76.8″ 170 – 195 cm |
70.9″ – 80.7″ 180 – 205 cm |
| Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| A: Seat Tube Length | 16.3 | 16.3 | 17.1 | 18.1 |
| B: Effective Top Tube | 22.6 | 23.4 | 24.5 | 25.6 |
| C: Stack | 24.4 | 24.8 | 25.2 | 25.5 |
| D: Reach | 17.1 | 17.9 | 18.9 | 19.9 |
| E: BB Height | 13.9 | 13.9 | 13.9 | 13.9 |
| F: BB Drop | 1.0 | 1.0 | 1.0 | 1.0 |
| G: Head Tube Length | 4.3 | 4.7 | 5.1 | 5.5 |
| H: Head Tube Angle | 64.0 ° | 64.0 ° | 64.0 ° | 64.0 ° |
| I: Seat Tube Angle | 77.5 ° | 77.5 ° | 77.5 ° | 77.5 ° |
| J: Standover Height | 27.6 | 27.6 | 27.6 | 27.6 |
| K: Chainstay Length | 17.6 | 17.6 | 17.6 | 17.6 |
| L: Wheelbase | 48.1 | 49.1 | 50.3 | 51.4 |
| Crank Arm Length | 160 mm | 160 mm | 160 mm | 160 mm |
| Stem Length | 40 mm | 40 mm | 50 mm | 50 mm |
| Handlebar Width | 800 mm | 800 mm | 800 mm | 800 mm |
| Frame Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| Rider Height | 59.1″ – 68.9″ 150 – 175 cm |
63″ – 72.8″ 160 – 185 cm |
66.9″ – 76.8″ 170 – 195 cm |
70.9″ – 80.7″ 180 – 205 cm |
