Pivot Shuttle SL Team XTR E-Bike
Original price was: $11,050.00.$7,982.00Current price is: $7,982.00.
‘
Pivot Shuttle SL Team XTR E-Bike
Conquer The Trail
E-bikes are the perfect way to get around on the trails. With the extra pedal assistance, you’ll be able to climb back to the top after a long descent so you can do it all over again. The Pivot Shuttle SL Team XTR E-Bike is an all-mountain e-MTB that is ready to take you to new heights or take you to new locations. Pivot emphasized light weight, refined suspension, crisp handling, and game-changing performance. The full carbon Hollow Core frame uses 150mm of travel on the front and 132mm of DW-Link suspension on the rear. With the seamless integrated FAZUA Ride 60 drive system and integrated 430Wh battery, you’ll be able to quickly get back to the top of the hill so you can descend all over again. The frame features a flip chip so you can adjust the geometry, full-size water bottle compatibility, internal cable routing, drag-free pedaling without assistance, a magnetic charging port and cover, and integrated frame protection.
The Team XTR version of the Pivot Shuttle SL comes with a Shimano XTR M9100 12-speed drivetrain. With a 32T chainring up front and an ultra-wide 10-51T cassette on the rear, you’ll have no issues climbing or riding longer distances. Shimano XTR M9120 4-piston hydraulic disc brakes provide excellent stopping power so you can descend with confidence. Reynolds Blacklabel 309/289 XC Carbon Wheels are paired with Maxxis Dissector tires that can be set up tubeless for a smoother ride, better traction, and fewer flats. With the Fox Transfer Factory Dropper Post, you’ll be able to quickly lift and lower your saddle with the press of a lever for more efficient climbing and safer descending with a lower center of gravity.
Features
- Lightweight carbon fiber frame with a flip chip so you can adjust the geometry, full-size water bottle compatibility, internal cable routing, drag-free pedaling without assistance, a magnetic charging port and cover, and integrated frame protection
- Shimano XTR M9100 12-speed drivetrain performs exceptionally well in all riding conditions
- Shimano XTR M9120 4-piston hydraulic disc brakes provide excellent stopping power
- Tubeless-ready carbon rims and tires for a smoother ride, better traction, and fewer flats
- Fox Transfer Factory Dropper Post quickly lifts and lowers your saddle with the press of a lever
| Frame | Hollow Core Carbon Fiber |
|---|---|
| Fork | Fox Factory 36 29″, 44mm Offset, GRIP2, 150mm Travel |
| Rear Shock | Fox Factory Float X |
| Headset | Pivot Precision Sealed Cartridge |
| Shifters | Shimano XTR M9100 I-Spec EV, 12-Speed |
| Front Derailleur | ShimaNOPE |
| Rear Derailleur | Shimano XTR M9100, 12-Speed |
| Crankset | Rotor EKAPIC E-MTB 32T |
| Bottom Bracket | – |
| Chain | Shimano CN-M9100 12-Speed |
| Cassette | Shimano XTR M9100, 10-51T |
| Brakes | Shimano XTR M9120 4-Piston Hydraulic, Galfer 203/180mm Rotors |
| Wheelset | Reynolds Blacklabel 309/289 XC Carbon, Industry 9 Hydra 15×110/12x157mm Hubs |
| Tires | Maxxis Dissector 29×2.4″ WT, TR, 3C, EXO, MaxxTerra |
| Handlebar | Phoenix Race Low Rise Carbon, 780mm Wide |
| Stem | Phoenix Team Enduro/Trail, 45mm |
| Grips/Bar Tape | Phoenix Factory Lock-On |
| Seatpost | Fox Transfer Factory Dropper Post, S:150, M/L:175, XL:200mm Travel |
| Seatclamp | Bolt-Type |
| Saddle | Phoenix WTB Volt Team, Medium Width |
| Intended Use | All-Mountain, Trail |
| Motor | FAZUA Ride 60 Drive System, 60Nm Torque/450W Peak Power |
| Battery | Integrated 430Wh |
| Display | Integrated Display |
Note: Components are subject to change without notice.
| Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| A: Seat Tube Length | 368 | 394 | 432 | 470 |
| B: Effective Top Tube | 597 | 631 | 645 | 659 |
| C: Stack | 607 | 622 | 626 | 638 |
| D: Reach | 439 | 469 | 482 | 504 |
| E: BB Height | 352 | 352 | 352 | 352 |
| F: BB Drop | 21 | 21 | 21 | 21 |
| G: Head Tube Length | 95 | 112 | 117 | 130 |
| H: Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| I: Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| J: Standover Height | 674 | 677 | 682 | 687 |
| K: Chainstay Length | 430 | 430 | 432 | 436 |
| L: Wheelbase | 1185 | 1222 | 1239 | 1271 |
| Crank Arm Length | 165 mm | 165 mm | 165 mm | 165 mm |
| Stem Length | 45 mm | 45 mm | 45 mm | 45 mm |
| Handlebar Width | 780 mm | 780 mm | 800 mm | 800 mm |
| Frame Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| Rider Height | 5’2″ – 5’8″ | 5’7″ – 6’0″ | 5’10” – 6’2″ | 6’1″+ |
| Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| A: Seat Tube Length | 14.5 | 15.5 | 17.0 | 18.5 |
| B: Effective Top Tube | 23.5 | 24.8 | 25.4 | 25.9 |
| C: Stack | 23.9 | 24.5 | 24.6 | 25.1 |
| D: Reach | 17.3 | 18.5 | 19.0 | 19.8 |
| E: BB Height | 13.9 | 13.9 | 13.9 | 13.9 |
| F: BB Drop | 0.8 | 0.8 | 0.8 | 0.8 |
| G: Head Tube Length | 3.7 | 4.4 | 4.6 | 5.1 |
| H: Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| I: Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| J: Standover Height | 26.5 | 26.7 | 26.9 | 27.0 |
| K: Chainstay Length | 16.9 | 16.9 | 17.0 | 17.2 |
| L: Wheelbase | 46.7 | 48.1 | 48.8 | 50.0 |
| Crank Arm Length | 165 mm | 165 mm | 165 mm | 165 mm |
| Stem Length | 45 mm | 45 mm | 45 mm | 45 mm |
| Handlebar Width | 780 mm | 780 mm | 800 mm | 800 mm |
| Frame Size | Small | Medium | Large | Extra Large |
|---|---|---|---|---|
| Rider Height | 5’2″ – 5’8″ | 5’7″ – 6’0″ | 5’10” – 6’2″ | 6’1″+ |
